Reparaturanleitung für Yamaha 75 – 225 PS 4-Takt Bj. 2000 – 2004

Artikelnummer: CL-B791-2
18,64

Sofort aus Vorrat lieferbar

In Stock
Der Artikel ist vorrätig und der Versand erfolgt am nächsten Werktag (Mo-Fr). Zahlung mit Paypal, Kreditkarte oder Vorkasse erforderlich.
Andere Kunden kauften dies. 4 Kunde(n) haben das gerade in ihrem Einkaufswagen.
Artikelnummer: CL-B791-2 Kategorien: , ,

Models covered

2000-2004 YAMAHA 100 HP
2000-2004 YAMAHA 115 HP
2000-2004 YAMAHA 200 HP
2000-2004 YAMAHA 225 HP
2000-2004 YAMAHA 75 HP
2000-2004 YAMAHA 80 HP
2000-2004 YAMAHA 90 HP

560 pages

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Torque specifications / Engine operation / Fasteners / Lubricants / Gasket sealant / Galvanic corrosion / Protection from galvanic corrosion / Propellers / Specifications

CHAPTER TWO / TOOLS AND TECHNIQUES
Safety first / Basic hand tools / Test equipment / Service hints / Special tips / Mechanic¿s techniques / Specifications

CHAPTER THREE / TROUBLESHOOTING
Test equipment / Troubleshooting preparation / Operating requirements / Starting difficulty / Ignition system testing / Warning system / Starting system / Charging system / Fuses and wire harness / Engine speed limiting system / Trim system / Electrical testing / Engine noises / Cooling system / Gearcase / Specifications

CHAPTER FOUR / LUBRICATION, MAINTENANCE AND TUNE-UP
Tune-up / Submersion / Storage / Specifications

CHAPTER FIVE / SYNCHRONIZATION AND ADJUSTMENT
Fuel system / Ignition timing / Throttle linkage adjustment / Specifications

CHAPTER SIX / FUEL SYSTEM
Fuel tank / Fuel filter replacement / Primer bulb / Fuel pumps / Carburetor / Specifications

CHAPTER SEVEN / ELECTRICAL AND IGNITION SYSTEMS
Battery / Electric starting system / Starter motor / Charging system / Ignition system / Warning system / Specifications

CHAPTER EIGHT / POWER HEAD
Flywheel / Power head / Inspection / Specifications

CHAPTER NINE / GEARCASE AND MIDSECTION
Gearcase operation / Propeller removal and installation / Gearcase removal and installation / Water pump / Gearcase / Inspection / Specifications

CHAPTER TEN / MANUAL REWIND STARTER
Removal, repair and installation / Specifications

CHAPTER ELEVEN / POWER TRIM AND TILT REPAIR
Fluid filling / Air bleeding / Specifications

INDEX

COLOR WIRING DIAGRAMS

Zusätzliche Informationen

Gewicht 1,27 kg
